MERSEN at ELTRON – protection that reacts faster than a short circuit !

A frequency converter costing several thousand dollars and a security device that just happened to be "at hand"?

This usually ends up being an expensive lesson. Choose proven solutions.

At ELTRON, we rely on MERSEN !

It is a world-class manufacturer offering solutions for electrical safety and semiconductor protection.

MERSEN is a brand whose fuses are used in industrial drives, photovoltaic installations, power engineering, and critical infrastructure.




MERSEN range of low voltage (LV) protection products includes:

Selected products (nn) protect installations and devices (up to 1000VAC) against short circuits, overloads, surges, and electric shock.


  • low voltage fuses;
  • fast and ultra-fast fuses for protecting power electronics, including IGBT transistors;
  • fuse bases and disconnectors;
  • solutions for frequency converters (inverters), UPS emergency power supply systems, and PV photovoltaic installations;
  • IEC and UL compliant protection devices for industry and power engineering.

These are solutions for applications where every millisecond counts.



One standard for the whole world. And real protection for inverters.

Globalization and increasingly smaller drives mean one thing: it makes no sense to design separate versions of machines for IEC and UL; it is better for them to meet both standards at the same time.

Unfortunately, this is not always possible, which is why MERSEN's safety devices comply with both IEC and UL standards.

It also makes no sense to protect inverters with ordinary circuit breakers (MCBs) against the effects of short circuits and overloads.



So what is the best solution?

Modulostar® CUS101 base + FR10GR69V (Protistor®) fast fuses.

1. CUS101 base – one component instead of two

Instead of maintaining two warehouses (IEC and UL), it is possible to use one globally certified fuse base.

What are the benefits?


  • voltage up to 1000 V DC/AC (IEC) and 1000 V DC / 800 V AC (UL);
  • ideal solution for PV and 690 V networks;
  • PA6/PBT fire resistance – GWFI 960°C;
  • short-circuit capacity up to 200 kA;
  • Finger-Safe design with IP20 protection – safe replacement of the insert.

Less complications. More safety.


2. FR10GR series fast fuse (...) and miniature circuit breaker (MCB) – why is an MCB not enough?

A miniature circuit breaker (MCB) needs 10–20 ms to shut down a short circuit. The IGBT transistor contained in the inverter can be destroyed in less than 1 ms.

FR10GR (gR characteristic) works instantly:


  • tripping time < 1 ms;
  • very low I²t (approx. 140 A²s);
  • short-circuit capacity up to 160 kA;
  • effective protection of semiconductors.

The result? The proposed FR10GR series fast fuse(…) allows over 100 times less destructive energy to pass through than a typical overcurrent circuit breaker.



Why is it not worth buying cheap fuses ?

Because cheap fuse links often get damaged not due to failure but due to daily cyclic operation – intensive switching, start-stop drives, PV photovoltaic installations.


On the other hand, the FR10GR series fast fuse(…) offers:


  • pure silver fuse element;
  • a design adapted to cyclic operation;
  • stable parameters over time;
  • fewer unplanned shutdowns.

It should be remembered that a single failure of a modern frequency converter can cost much more than the entire stock of professional fuse inserts designed to protect power electronics, including the IGBT transistors contained in the aforementioned inverter.



So why choose and use Mersen solutions?
  • One global bill of materials (BOM) for the worldwide market, containing solutions compliant with IEC + UL;
  • Real, fast protection for semiconductors;
  • Lower risk of failure;
  • Lower costs in the long term.

If the protected system is to be effectively protected against the effects of short circuits and overloads, the protection must act faster.


Professional protection of particularly important UPS emergency power supply systems and frequency converters will reduce the risk of costly downtime.

Take advantage of the ELTRON promotion and choose solutions from MERSEN.



dol-mersen-bezpieczniki-eltron-en


Promotion conditions

This promotion is valid only for online purchases made on our website www.eltron.pl.

Promotion is valid from 04.03.2026 to 31.03.2026 or until warehouse stocks last.
